Training manual ALTEAS & GENUS ONE
Page. 46 of 88 Version 2V2.
6.2 PREMIX BURNER
The cylindrical stainless steel premix burner pot Ø 70 mm is made up of a small-diameter perforated
external casing on which the combustion occurs. a large-diameter perforated internal casing that balances
the propagation of the gas.
This burner can be used with natural gas and LPG.
1. Stainless Steel Burner
2. Ignition/detection electrode
