Ariston GENUS PREMIUM EVO 24

Training manual ALTEAS & GENUS ONE
Page. 79 of 88
9.3.3 Menù 4 : Zone 1 parameters
2
6
BOILER MANUAL SETTING
2
6
0
Manual mode attivation
0: Off
1: On
0
2
6
1
Boiler pump control
(set parameter 260 =1)
0: Off
1: On (timed 10 min)
0
2
6
2
Fan control
(set parameter 260 =1)
0: Off
1: On (timed 10 min)
0
2
6
3
3 way valve control
(set parameter 260 =1)
0: Sanitary
1: Heating ( timed 10 min)
0
2
7
TEST & UTILITIES
2
7
0
Flue cleaning function
0: Off
1: On (select desired power)
0
2
7
1
Air Purge function
0: Off
1: On
0
2
7
2
Automatic calibration
0: Off
1: On
0
2
8
RESET MENU’
2
8
0
Reset menu 2 factory setting
YES: press button “OK”
NO: press button “ESC”
/
Menù
Sub Menù
Parameter
Function
Range
Default
setting
4
0
SETPOINT
4
0
2
Temperature setpoint zone 1
Par 425 ÷ Par 426
/
4
2
ZONE 1 SETTING
4
2
0
Select high or low temperature
for zone 1
0: low temperature
1: high temperature
1
4
2
1
Thermoregulation mode
selection
0: fixed delivery temperature
1: basic thermoregulation
2: only room probe
3: only outside probe
4: room probe + external probe
1
4
2
2
Select thermoregulation curve
0_2 ÷ 1_0 (par. 420=0)
1_0 ÷ 3_5 (par. 420=1)
(with Auto function enabled)
0_6 (par 420=0)
1_5 (par 420=1)
4
2
3
Select thermoregulation curve
parallel shifting
-7 ÷ 7 (par. 420=0)
-14 ÷ 14 (par. 420=1)
(with Auto function enabled )
0
4
2
4
Influence of the room probe on
thermoregulation
0 ÷ 20
(with Auto function enabled )
20
4
2
5
Zone 1 maximum heating
temperature (°C)
20 ÷ 45 (par. 420=0)
35 ÷ 82 (par. 420=1)
45 (par. 420=0)
82 (par. 420=1)
4
2
6
Zone 1 minimum heating
temperature (°C)
20 ÷ 45 (par. 420=0)
35 ÷ 82 (par. 420=1)
20 (par. 420=0)
35 (par. 420=1)
4
3
DIAGNOSTICS
4
3
2
Zone 1 delivery temperature
(°C)
(only visualization)
/
4
3
3
Zone 1 return temperature (°C)
(only visualization)
/
4
3
4
Heating request by zone 1
OFF: no
ON: yes
(only visualization)
/
