Arjo MAXI MOVE - Page 25

25
Using your Maxi Move
level with the top of the head (see Fig. 40). With the
stretcher frame as high up as possible, move the lift until
the frame is directly over the patient.
Fig. 40
The frame is symmetrical and can be used from either
side (see Fig. 41).
Fig. 41
Lower the stretcher frame carefully over and just clear of
the patient, aligning the center of the frame
approximately over the patient’s navel. Connect all the
sling loops securely (see Fig. 42).
Fig. 42
Raise and move the patient away from the bed (see Fig.
43).
Fig. 43
Rotate the stretcher frame until the patient’s feet are
close to the mast (see Fig. 44). In this position, the
complete unit may be moved through wide doorways.
Otherwise, leave the stretcher perpendicular to chassis
legs. In this position, the lift and patient can be moved
through a doorway sideways.
Fig. 44
NOTE: The attachment straps have several
connection loops. Choose whichever loop is
considered the best to enable the patient to lie
in the most comfortable position.
WARNING: It is essential to keep the patient at
approximately the height of the bed to ensure
stability of the unit and to maintain patient/
attendant contact.
When lowering the stretcher frame, ensure
that the patient’s and attendant’s legs and feet
are well clear of the moving mast.
WARNING: Only use soft stretchers that have
all blue colored attachment straps.
Note: The “head end” straps have a black tab
stitched to them that can be used with other
ARJO stretcher frames.
Do not use any other type of soft stretcher
sling with the Maxi Move.
