Patient Scale Information
Fig. 54
Key to Scale (Fig. 54)
1. Scale display on handset
2. Operating buttons on handset
3. Jib
4. Spreader bar
5. Load cell cover
If your Maxi Move has been equipped with an ARJO
scale, your lift will have the added advantage of being
able to weigh patients once they have been lifted.
Descriptive Marking/Seals C.E.
Units only
After inspection, the following marks will be found on
the scale label (see Fig. 55):
• CE mark (signifying compliance with Council
Directive 93/42/EEC for medical devices and
Council Directive 90/384/EEC for non-automatic
weighing instruments, followed by the two digits of
the year in which it was affixed).
• The identification number of the notified body that
has carried out the EC surveillance.
• A green sticker bearing a capital letter ‘M’ in black
(signifying that the scale is suitable for an approved
application in accordance with Council Directive 90/
384/EEC).
• The number of the EC type approval certificate.
• The accuracy class.
• The maximum capacity.
• The minimum capacity
• Verification scale interval.
• Calibration counter
• Gravity configuration counter
• A seal bearing the identification and number of the
inspection body.
Fig. 55
WARNING: The scale has been designed to
weigh hospital or care facility patients under
the supervision of trained nursing staff. Avoid
any other uses.
