Arjo MAXI MOVE - Product Description;Functions; Parts Referred to in this Manual

9
Parts Referred to in this Manual
Fig. 3
1
2
3
6
7
9
8
10
11
5
12
13
14
15
4
1) Mast
2) Mast top cover
3) Maneuvering handle
4) Lift battery pack
5) Braked casters
6) Adjustable chassis legs
7) Medium DPS spreader bar (if included)
8) “Lock and Load” spreader bar carrier system
9) Jib
10) Control panel
11) Control handset
12) Stop button
13) Power button
14) Battery release button
15) Battery charger
16) Two-point loop spreader bar (if included)
17) Combi medium loop spreader bar (if included)
18) Four-point loop spreader bar (if included)
19) Small DPS spreader bar (if included)
20) Medium powered DPS spreader bar (if included)
21) Large powered DPS spreader bar (if included)
22) Stretcher frame (if included)
Product Description/Functions
