Diagnostics
High
-Definition DVR DCX3520e-M • Installation Manual
56
365
-095-25080-x.1
Current Channel Status
This diagnostic displays a status of the last attempted channel you attempted to tune on the in-band
stream. The channel type determines the status display.
Figure 31: Current Channel Status Diagnostic Screens
Figure 32: Current Channel Status Front Panel Displays
Digital channel indicator
Epoch authorization code
Purchasable indicator
Preview indicator
Digital channel:
