Memory Configuration
This diagnostic displays the DCX3520e-M memory configuration. The information is updated when you
display the diagnostic.
Figure 37: Sample Memory Configuration Diagnostic Screen
Note: There is no front panel display for this diagnostic.
Table 18: Memory Configuration Diagnostic Field Descriptions
Field Description
System RAM
The allocated system RAM in MB.
Flash
The allocated flash memory in MB.
NVRAM
The allocated NVRAM in KB.
