Arris DCX3520e-M - Page 68

Diagnostics
High
-Definition DVR DCX3520e-M • Installation Manual
58
365
-095-25080-x.1
Field Description
Tuned Frequency
(Digital channels only) The center RF carrier frequency for the digital service. It can be From 54 to 860
MHz.
VCT ID
Virtual Channel Table ID
SOC
The Selectable Output control is enabled or disabled.
CCI
The copy control information:
00 — copy free
01 — no more copies
10 — copy once
11 — never copy
N/A — the value is invalid or cannot be retrieved
APS
The Analog Protection System; for example, Macrovision:
00 — no Macrovision
11 — Type 3 Macrovision
N/A — the value is invalid or cannot be retrieved
RC Flag
Displays whether the broadcast flag is present:
0 — no flag/not defined
1 — the flag is present/enabled
N/A — the value is invalid or cannot be retrieved
CIT
The constrained image trigger, as delivered in the PRK or the Set DRM API:
1 — set
0 — not set
N/A — the value is invalid or cannot be retrieved
DRM
The digital rights management valid flag bit:
1 — set
0 — not set
N/A—the value is invalid or cannot be retrieved
RS
The retention state:
Forever, 1 week, 2 days, 1 day, 12 hours, 6 hours, 3 hours, 90 minutes, or Not Defined
N/A —value is invalid or cannot be retrieved
SDV Client Status
If Switched digital video is available, the following information is related to the SDV Client:
• Status of client
• IP Address of primary switched video manager (SVM) server
• IP Address of secondary switched video manager (SVM) server
• IP Address of Auto Discovery server
• SDV Mode
• MotoCar configuration and message count
• Version number of the SDV configuration message and number of minutes since the version was
