ASCOM Eurit 22 User Manual

Installation and startup
Eurit 22 telephone
Handset
Telephone connection cable
Handset cable
Perspex cover for label
Operating Manual
The connection sockets are on the base of your
telephone. First connect the handset by plugging
the longer end of the coiled handset cable into the
small socket on the base of the telephone 0.
When plugging in the connector, ensure that you
hear it click into place. Lead the cable through the
strain-relief groove 0 and plug the connector on
the short end of the cable into the handset 0. Give
the cable a slight tug to ensure that the connector
has locked into place.
Now connect the telephone by plugging the
telephone cable into the larger socket on the base
of the telephone 0. When plugging in the
connector, ensure that you hear it click into place.
Give the cable a slight tug to ensure that the
connector has locked into place. Lead the cable
through the strain-relief groove 0 and plug the
connector on the other end of the cable into the
telephone socket 0.
a
Once you have connected your Eurit 22, the following prompt is displayed:
“Please enter at least one MSN (subscriber number) including name <OK> ‘.
Please read the section entitled “Display on startup I’ under “Basic Settings I’.
Wall mounting
Your Eurit 22 can also be wall-mounted.
e
For the wall-mounting kit please contact your local supplier
Insert the plastic feet in the appropriate slots in the housing base 0. Fasten the two screws to
the wall and hang your Eurit 22 by clipping the screw heads into the two holes on the telephone
base 0.
