Instructions for Installation of
Keypad Rim & Mortise Exit Devices
KP8877 / KP8878
KP8977 / KP8978
Note: The following tests are used to check basic functionality of the keypad and inside controller.
Power On Self Test (POST) for new KP controllers only (released after 1/2021)
• Immediately after installing the batteries, verify the following keypad sequence:
• Green LED flashes quickly - (5) times a second
• Yellow LED flashes quickly - (5) times a second
• Beeps 3 times quickly - (3) times a second
The following tests are for existing Legacy and New KP controllers and take approximately
1 to 2 seconds each:
• Enter ‘7890#123456*’ - each key beeps when pressed (if key beep is activated)
• Verify the following keypad sequence:
Green LED flash, Yellow LED flash, 3 beeps
If you have the optional DTD
• Set DTD to printer mode, press (center) enter key on DTD once
• Align DTD Infrared port 1 – 3” from the top right side keypad Infrared transmitting LED
• Press enter key on DTD again just before the * key in the following step
• Enter ‘7890#123456*’ - each key beeps when pressed (if key beep is activated)
• Verify the following on keypad/DTD sequence:
Green LED flash, Yellow LED flash, 3 quick beeps, “IR OK” is displayed on DTD
Troubleshooting Instructions
10
Copyright © 2014. 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved.
Reproductions in whole or in part without express written permission of Sargent Manufacturing Company is prohibited.
02/28/21
27 A7137D • 800-810-WIRE (9473) • www.sargentlock.com
