Rim Installation Instructions for KP8800 Series
NOTE: BEFORE STARTING
• This device is non-handed
• Door should be fitted and hung
• Verify box label for size of exit device, function and hand
• Install mullion in frame, if used
Step #1 Exit Hardware & Door Prep
Prep door according to installation instruction sheet A6770.
Left Hand
Reverse Bevel
“LHRB”
Outside
Right Hand
Reverse Bevel
“RHRB”
Inside
• Data Transfer Device (DTD) - used to download the user
and transaction type.
• Remote Unlocking - 52-2071 - used for remote unlocking
of motorized “ET” outside trim
Optional Equipment
Remote
unlocking
connector
placement
Parts Breakdown (Continued)
7
Inside Escutcheon
Copyright © 2014. 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved.
Reproductions in whole or in part without express written permission of Sargent Manufacturing Company is prohibited.
02/28/21
7 A7137D • 800-810-WIRE (9473) • www.sargentlock.com
KP8877/KP8878 x ET x Lever Design
Keypad Operated RIM Exit Device
