1.2 I Hydraulic connecons
• The appliance will be connected with a Ø50 PVC pipe, using the half union connectors supplied (see § “5.1 I
Descripon”), to the pool's ltraon circuit, aer the lter and before the water treatment.
• Respect the direcon of hydraulic connecon.
• A by-pass must be installed to make it easier to work on the appliance.
50 cm
50 cm
250
cm
: water inlet valve
: by-pass valve
: water outlet valve
* minimum distance
: water inlet adjustment valve (oponal)
: water outlet adjustment valve (oponal)
: water treatment
Connecon to a standard ltraon circuit
To evacuate the condensates:
• Raise at least 10 cm the appliance with an-vibraon pads,
• Fit the two condensate drainage pipes to the openings located under the appliance base (supplied).
Locaon for connecng the condensate drainage pipes (seen from below the appliance)
Tip: condensate drainage
• Cauon, several litres of water can be drained from your appliance each day. We strongly recommend
connecng the drain to a suitable water drainage system.
