• Open the top panel ( ) with a screwdriver (4 screws) to access the electrical terminal block.
• Insert the power supply cable ( ) into one of the cable gland ( ) on the rear part of the appliance.
• Inside the appliance, x the power supply cable by threading it through the cable clamp ( ) (maintained with one
screw).
Accessing the electrical terminal block
• Connect the power supply cable to the terminal block inside the appliance as following.
L: Live
N: Neutral
: Earth
Connect to
power supply
Connect opons
(ltraon pump,
power supply relay),
see”1.4 I Opon
connecons”.
Terminal block for single-phase power
• Carefully close the top panel.
