ROG Striker II Extreme / Striker II NSE 2-17
5. Follow Step 1 to 4 to install the other optional fan.
6. The photo shows that two fans are
installed to the motherboard.
Plug the optional fan cable in the PWR_FAN connector on the motherboard.
