2-18 Chapter 2: Hardware information
Channel Sockets
Channel A DIMM_A1 and DIMM_A2
Channel B DIMM_B1 and DIMM_B2
2.4 System memory
2.4.1 Overview
The motherboard comes with four Double Data Rate 3 (DDR3) Dual Inline Memory
Modules (DIMM) sockets.
A DDR3 module has the same physical dimensions as a DDR3 DIMM but is
notched differently. DDR3 modules are developed for better performance with less
power consumption.
items. Refer to the table below for details.
STRIKER II EXTREME
DIMM_A1
DIMM_A2
DIMM_B1
DIMM_B2
STRIKER II EXTREME/
STRIKER II NSE 240-pin DDR3 DIMM sockets
FSB 1600 1333 1066
DDR3
1600 1333 1066 1333 1066 888 800 1066 852 800 710
