ROG Striker II Extreme / Striker II NSE 2-45
5
6
5. Connect the assembled tube to the waterblock and tighten the screw of the
clamp using a screwdriver.
6. Repeat Step 1 to 5 for another tube. Make sure that both tubes are well
3
2
1
4
For watercooling system with 1/2” or 10mm ID tubes
Your watercooling system may come with tube clamps. Use a clamp to fasten
3. Loosen the screw of a 1/2” ID tube clamp and hitch it to the bottom end of the
3/8” ID tube. Tighten the clamp screw with a screwdriver.
4. Hitch another clamp to the top end of the 3/8” ID tube.
