ASUS ESC4000A-E12
3-19
13. BF Power connector (6-pin BFPWR1)
This connector supplies power to the optional BlueField Ethernet DPU card. The 6-pin
ATX power supply plug is designed to fit this connector in only one orientation. Find the
proper orientation and push down firmly until the connector completely fits.
This power connector supplies a maximum of 150W and is only intended for use with a
Bluefield Ethernet DPU card.
