ASUS RS720-E9-RS8/RS8-G
1-11
1
2
3 4
1
2
3 4
The barebone server does not include a oppy disk drive. Connect a USB oppy disk drive
to any of the USB ports on the front or rear panel if you need to use a oppy disk.
WARNING
HAZARDOUS MOVING PARTS
KEEP FINGERS AND OTHER BODY PARTS AWAY
1. Redundant Power supply
2. ASUS Z11PP-D24 Server
Board
3. GPU fans
4. System fans
5. SATA/SAS back panel
6. 8 x 2.5”/3.5” storage device
trays
7. Front panel (hidden)
8. Asset tag (hidden)
A protection lm is pre-attached to the front cover before shipping. Please remove the
protection lm before turning on the system for proper heat dissipation.
RS720-E9-RS8-G
