Asus RS720Q-E9-RS8 User Manual

RS720Q-E9-RS8 Series
1-5
Model Name RS720Q-E9-RS8 RS720Q-E9-RS8-S
Rear I/O Connectors
Per Node:
2 x USB 3.0 ports
1 x VGA port
2 x RJ-45 GbE LAN ports
1 x RJ-45 Mgmt LAN port
Switch/LED
Per Node:
Rear Switch/LED:
1 x Q-Code/Port 80 LED
1 x Power switch LED
Front Switch/LED:
1 x Power switch/LED
1 x Location switch/LED
1 x Message LED
LAN 1-2 LED
Management
Solution
Software
ASUS Control Center (Classic)
Out of Band
Remote
Management
On-Board ASMB9-iKVM for KVM-over-IP
OS support
Windows
®
Server 2016
Windows
®
Server 2012 R2
RedHat
®
Enterprise Linux
SuSE
®
Linux Enterprise Server
CentOS
Ubuntu
VMware
Citrix XenServer
* Please find the latest OS support from http://www.asus.com/
Regulatory Compliance
BSMI, CE, C-TICK, FCC (ClassA)
Dimension
800mm x 444mm x 88mm(2U)
31.5" x 17.48" x 3.46"
Gross Weight Kg
41.5 kg
Net Weight Kg (CPU, DRAM,
and HDD not included)
32.5 kg
Power Supply
(following different
configuration by region)
1+1 Redundant 1600/2200W 80 PLUS Platinum Power Supply
Rating: 200-240Vac, 9.5A (for each inlet), 47-63Hz, Class I
Environment
Operation temperature: 10° ~ 35°
Non operation temperature: -40° ~ 60°
Non operation humidity: 20% ~ 90% ( Non condensing)
Specications are subject to change without notice.
