Asus RS720Q-E9-RS8 User Manual

Chapter 4: Motherboard Information
4-4
4.1.1 Layout contents
Jumpers Page
1. Clear RTC RAM (CLRTC1) 4-5
2. VGA controller setting (3-pin VGA_SW1) 4-6
3. LAN controller setting (3-pin LAN_SW1, LAN_SW2) 4-6
4. ME rmware force recovery setting (3-pin ME_RCVR1) 4-7
5. DDR4 thermal event setting (3-pin DIMMTRIP1-2) 4-7
6. BMC Setting (3-pin BMC_EN1) 4-8
7. PMBus 1.2 PSU select jumper (3-pin SMART_PSU1) 4-8
8. Chassis Intrusion (2-pin INTRUSION1) 4-9
9. DMLAN setting (3-pin DM_IP_SEL1) 4-9
10. PCH_MFG setting (3-pin PCH_MFG1) 4-10
Internal connectors Page
1. Trusted Platform Module connector (20-1 pin TPM1) 4-11
2. Serial port connector (10-1 pin COM1) 4-11
3. OMNIP connector (24-pin OMNIP1) 4-12
4. VROC_KEY connector (4-pin VROC_KEY1) 4-12
5. VGA connector (16-1 pin VGA_HDR1) 4-13
6. Mezzanine PCI card connectors (MEZZPCIE1; MEZZPCIE2) 4-13
7. Power connector 4-14
Internal LEDs Page
1. BMC LED (BMCLED1) 4-15
2. Standby Power LED (SBPWR1) 4-15
3. Message LED (MESLED1) 4-16
4. Location LED (LOCLED1) 4-16
Mid Plane jumper Page
1. 12V_SEL1 jumper 4-17
