Asus RS720Q-E9-RS8 User Manual

2-3
RS720Q-E9-RS8 Series
2.2 Air Duct
The RS720Q-E9-RS8 series server system comes with a motherboard fan air duct to enable
better air ow inside the motherboard while the system is running.
Removing the air duct
1. Remove the screws securing the air duct in place.
2. Carefully lift the air duct out of the chassis.
Position the air duct on top of the motherboard then carefully t it on top of the motherboard.
Refer to the following illustration for the right orientation of the air duct.
Installing the air duct
Ensure that the air duct is rmly tted to the motherboard.
Insert the air duct on the gaps between the memory slots.
