Asus RS720Q-E9-RS8 User Manual

RS720Q-E9-RS8 Series
1-9
1 2
1 2
Mgmt
PORT80
1 2
Mgmt
PORT80
1 2
Mgmt
PORT80
1 2
Mgmt
PORT80
1 2
Mgmt
PORT80
1 2
Mgmt
PORT80
1 2
Mgmt
PORT80
1 2
Mgmt
PORT80
1 2
1 2
1 2
1 2
1 2
1.7 LED information
1.7.1 Front panel LEDs
LED Icon
Display
status
Description
Power LED
ON System power ON
Message LED
OFF System is normal; no incoming event
ON A hardware monitor event is indicated
LAN LEDs
OFF No LAN connection
Blinking LAN is transmitting or receiving data
ON LAN connection is present
Location LED
ON Location switched is pressed
OFF Normal status (Press the location switch again to turn off.)
Message LED
Power button with LED
Message LED
Power button with LED
LAN2 LED
LAN1 LED
Location button with LED
LAN2 LED
LAN1 LED
Location button with LED
