RS720Q-E9-RS8 Series
1-7
* This port is for ASUS ASMB9-iKVM controller and for technicians only.
1.5 Rear panel features
LAN port 2
LAN port 1
Power button
Q-Code/Port 80 LED
DM management LAN port*
USB 3.0 ports
VGA port
PSU 1
Node 3
Node 1
Node 4
Node 2
PSU 2
When installing only two nodes, install the nodes to node slot number 1 and 3 or number 2
and 4.
RS720Q-E9-RS8 / RS720Q-E9-RS8-S
Z11PH-D12 (Node)
