Chapter 2: Hardware Information
2-12
3. Remove the screw from the metal bracket on the riser card, then remove the metal
brackets from the riser card.
4. Prepare the expansion card.
Before installing an expansion card, read the documentation that came with it and ensure to
make the necessary hardware settings.
5. Align and insert the golden nger connectors of the expansion card to the PCI-E slot
connector on the riser card as shown.
6. Secure the expansion card with the screws removed earlier.
To Next Page
