Chapter 2: Hardware Information
2-20
Connect N4_MSASHD1 on the Backplane to N4_OCUSAS1 on the Upper Mid
Plane
Connect N3_MSASHD1 on the Backplane to N3_OCUSAS1 on the Lower Mid
Plane
Connect N2_MSASHD1 on the Backplane to N2_OCUSAS1 on the Upper Mid
Plane
Connect N1_MSASHD1 on the Backplane to N1_OCUSAS1 on the Lower Mid
Plane
Connect N4_OCUPCIE2 on the Backplane to N4_OCUPCIE2 on the Upper Mid
Plane
Connect N4_OCUPCIE1 on the Backplane to N4_OCUPCIE1 on the Upper Mid
Plane
Connect N3_OCUPCIE2 on the Backplane to N3_OCUPCIE2 on the Lower Mid
Plane
Connect N3_OCUPCIE1 on the Backplane to N3_OCUPCIE1 on the Lower Mid
Plane
Connect N2_OCUPCIE2 on the Backplane to N2_OCUPCIE2 on the Upper Mid
Plane
Connect N2_OCUPCIE1 on the Backplane to N2_OCUPCIE1 on the Upper Mid
Plane
Connect N1_OCUPCIE2 on the Backplane to N1_OCUPCIE2 on the Lower Mid
Plane
Connect N1_OCUPCIE1 on the Backplane to N1_OCUPCIE1 on the Lower Mid
Plane
