(4-2) Creating Data Table
(4-2-1) Definition and Format of Data Table
① The data table consist of the following three definitions: temperature, Refractive Index, and
Concentration.
②The maximum number of data points possible is: 6 for temperature and 7 for Concentration.
③The temperature is displayed by 3 digits and 1 decimal place (000.0).
The Concentration is expressed by a 6-digit number.
A decimal point can be placed anywhere within the 6 digits.
The Refractive Index (nD) is expressed by a 5-digit number.
In case of a 4-digit number, add a "0 (zero)" at the end to make it 5 digits long.
④Create a table based on the information above.
Table 11-1
※C1～C7：Concentration or dilution coefficient, etc.
Enter up to 7 points. Fill in any blank cells with "0.0".
Input condition :
C1＜C2＜C3＜C4＜C5＜C6＜C7
C1＞C2＞C3＞C4＞C5＞C6＞C7
※T1～T6：Measurement temperature
Enter up to 6 points. Fill in blank cells, if any, with "0.0".
Input condition:
T1＜T2＜T3＜T4＜T5＜T6
※nD10～nD66：Refractive Index (nD) by Concentration and by temperature
Input condition :
nD10＜nD11＜nD12＜nD13＜nD14＜nD15＜nD16
nD20＜nD21＜nD22＜nD23＜nD24＜nD25＜nD26
nD30＜nD31＜nD32＜nD33＜nD34＜nD35＜nD36
nD40＜nD41＜nD42＜nD43＜nD44＜nD45＜nD46
nD50＜nD51＜nD52＜nD53＜nD54＜nD55＜nD56
nD60＜nD61＜nD62＜nD63＜nD64＜nD65＜nD66
※Fill in any blank cells with "0.0."
※If the measured value is outside the range in this table, "LLLLLL" or "HHHHHH" is displayed.
※If the measured temperature is outside the range in this table, "d. Err" is displayed.
