ATEN CS1732B User Manual

1. Introduction
7
No. Component Description
1Port
Selection
Pushbuttons
Pressing a front panel pushbutton brings the focus to the
computer attached to its corresponding port.
There are two settings for Front Panel Pushbutton Switching
Operation: MODE 1 (Default Setting) and MODE 2 (Alternative
Setting). The F6:SET function in the OSD allows you choose
between these two settings. See F6: SET, page 31.
For full details of the MODE 1 (Default) and MODE 2
(Alternative) Front Panel Pushbutton Switching Operation
settings, see BUTTON SETTINGS, page 32.
2 Port LEDs The Port LEDs are built into the Port Selection Switches. The
upper ones are the KVM Port LEDs; the lower ones are the
USB LEDs:
KVM:
 Lights DIM ORANGE to indicate that the
computer attached to its corresponding port is up
and running (On Line).
 Changes to BRIGHT ORANGE to indicate that
the computer attached to its corresponding port is
the one that has the KVM focus (Selected).
 Flashes to indicate that the computer attached to
its corresponding port is being accessed under
Auto Scan mode.
USB:
 Lights DIM GREEN to indicate that there is a
USB cable connection to the computer attached
to its corresponding port. Does not light if there is
no USB connection to the computer.
 Changes to BRIGHT GREEN to indicate that the
computer attached to its corresponding port is the
one that has access to the USB peripherals.
3 Console
Connectors
(Audio)
Your main console microphone and speakers plus in
here.These audio ports have priority over the ports in the rear
panel.
4 USB 2.0
Peripheral
Port
USB peripherals (printers, scanners, etc.) can plug into either
port.
