UM-23900B-U User manual ATEQ CDF60 Page 4/40
2. MEASUREMENTS CHARACTERISTICS
2.1. FLOW MEASUREMENT RANGES
Flow
ranges
Standard Option (*)
Maximum
resolution
4 ml/min
2% RV + 0,01 ml/min 1% RV + 0,01 ml/min 0,001 ml/min
Accuracy in
conditions
defined as
ambient
No linearity +
Hysteresis +
Repeatability + T° drift
+ Long time drift (90
days)
40 ml/min
2% RV + 0,1 ml/min 1% RV + 0,1 ml/min 0,01 ml/min
4 ml/min
2,5% RV + 0,01 ml/min 2% RV + 0,01 ml/min 0,001 ml/min
Accuracy in
conditions
defined as
standard
(1013 hPa -
20°C)
No linearity +
Hysteresis +
Repeatability + T° drift
+ Long time drift (90
days)
40 ml/min
2,5% RV + 0,1 ml/min 2% RV + 0,1 ml/min 0,01 ml/min
RV = Read value.
(*) Instrument adjusted in our metrology laboratory with COFRAC agreement.
2.2. ATMOSPHERIC PRESSURE AND TEMPERATURE INDICATORS
Minimum Maximum
Accuracy
(20°C)
Atmospheric pressure
850 hPa 1050 hPa +/- 200 Pa
Temperature (internal)
0° C 50° C +/- 1,5%
Note: the zero offset linked to the temperature or the position can be take over by an
auto-zero. It is however advised to make an auto-zero before a measurement.
Recommendation of use: according to some use's conditions, the instrument can put
to two hours of time of heating before complete stabilization.
