Chapter 1 – Instrument installation
UM-23900B-U User manual ATEQ CDF60 Page 5/40
Chapter 1
INTRUMENT INSTALLATION
Before the first use of the instrument, make a complete battery
charging, wait until the CHARGE light is off.
1. PRESENTATION OF THE ATEQ CDF60
The ATEQ CDF60 is according a portable case.
The instrument has a pneumatic quick connector (Staublï kind) for the connection to the
flow to be measured.
The instrument has three electrics connectors:
¾ 1 connector for the battery charge, the instrument run with lithium-ion batteries
under 12 V DC voltage and it supplies with a specific supply transformer to
charge the batteries.
¾ 1 RS232 connector.
¾ 1 USB connector.
Display
Keyboard
Pneumatic
Connector
Charging
battery
connector
USB and RS232
connectors
