3.8. RS232
This parameter is configuring the RS232 port.
Enter into the parameters menu, by pressing and
old the ENTER
during 3 seconds.
+/
-
40
.
00
cm
3/
m
i
n
AIR STD.COND.
FLOW : 09.36
TEMP. : 25.8°C
ATM.P : 1010.5 hPa
The PARAMETER menu is displayed. By using the
UP
and DOWN key select RS232
parameter.
PARAMETER
TEMP.UNIT.: CELSIUS
AUTO OFF: 05 min
>
RS232
Then press the ENTER key to enter into the
RS232 links parameters configuration menu.
RS232
>BAUDRATE : 57600
BITS COUNT : 8
P
ARITY :
N
ONE
Select and adjust each parameter: BAUDRATE,
BITS COUNT, PARITY, HANDSHAKE by using
the UP and DOWN key and validate
with the ENTER
key.
RS232
BAUDRATE : 19200 <
BITS COUNT : 8
P
ARITY :
N
ONE
To return to the measurement mode, press
CANCEL
.
+/
-
40
.
00
cm
3/
m
i
n
AIR STD.COND.
FLOW : 09.36
TEMP. : 25.8°C
ATM.P : 1010.5 hPa
