Chapter 3 – Start up, adjust and measures
UM-23900B-U User manual ATEQ CDF60 Page 12/40
2. MEASURES DISPLAY
The instrument displays continuously the current flow. There's no measurement start
cycle.
There are two display modes:
¾ The simple mode where only the current flow is displayed.
-
40
.
00
cm
3/
m
i
n
AIR STD.COND.
0
9
.36
¾ The extended mode where all the measures are displayed: flow, internal
instrument temperature and atmospheric pressure.
-
40
.
00
cm
3/
m
i
n
AIR STD.COND.
FLOW : 09.36
TEMP. : 25.8°C
ATM.P : 1010.5 hPa
To switch from the simple mode to the extended mode, press the UP
or the
DOWN
keys.
Display description (extended mode):
+/- 40.00 cm3/min
AIR STD.COND.
FLOW : 09.36
TEMP. : 25.8°C
ATM.P : 1010.5 hPa
Selected gas
Instrument
range
Displayed if
standard
conditions are
validated
Current flow
Temperature
Atmospheric
pressure
Note: the data sending on the RS232 frame is different according to the display mode
selected, in simple mode, only the current flow is sent, in extended mode, the three
measures are sent.
