Operation Overview EN STbench
28
© Atlas Copco Industrial Technique AB - 9839 0880 01
A Battery status indicators and Battery Charger
switch
B Ethernet port
C Serial cable port D USB ports (two)
E Brake pressure indicator F External transducer sockets
G Start PC / Stop PC
The brake pressure indicator is not present on static benches.
The main panel is marked with the following symbols:
Symbol Description
Ethernet port
USB port
External transducer socket
Documentation must be consulted
Below the main panel, the power supply socket:
