Atlas Copco STbench User Manual

Operation EN STbench
46
© Atlas Copco Industrial Technique AB - 9839 0880 01
Doing a test with a brake place on the Articuated arm
For further details about how to execute a free test on the STbench according to the tool, refer to the
“STbench Configuration Manual”.
1. Unlock the locking device of the Articulated arm and arrange the Articulated Arm in the desired posi-
tion.
2. Lock the Articulated arm by using the locking device of the arm.
3. Run the test configured on STbench.
4. By means of the correct adapter, position the tool on the brake, and ensure that it reacts against the
reaction bar before starting the test (refer to the picture below):
