8.2.3 Performance data
At reference conditions, if applicable, and at normal shaft speed, unless otherwise stated.
1)
Free air delivery is measured according to ISO 1217 ed.3 1996 annex D
Designation XRHS 506 -
XRHS 1100 CD6
XRVS 476 -
XRVS 1000 CD6
Engine shaft speed, normal and maximum r/min 1600 1600
Engine shaft speed, compressor unloaded r/min 1200 1200
Free air delivery (FAD)
1)
Standard l/s 500 460
cfm 1059 975
Aftercooler option l/s 490 450
cfm 1038 953
Fuel consumption at
- 100% FAD Fuel expert kg/h 62.3 62.1
lb/h 137.4 136.9
No Fuel expert kg/h 62.3 62.1
lb/h 137.4 136.9
- 75% FAD Fuel expert kg/h 46.8 47
lb/h 103.2 103.6
No Fuel expert kg/h 55.4 55.4
lb/h 122.1 122.1
- 50% FAD Fuel expert kg/h 38.8 39.2
lb/h 85.5 86.4
No Fuel expert kg/h 46.8 47.2
lb/h 103.2 104.1
- 25% FAD Fuel expert kg/h 33.9 34.6
lb/h 74.7 76.3
No Fuel expert kg/h 35.9 36.7
lb/h 79.2 80.9
- unload Fuel expert kg/h 29 30.2
lb/h 63.9 66.6
No Fuel expert kg/h 29 30.2
lb/h 63.9 66.6
Specific fuel consumption g/m
3
34.6 37.5
dram/cu.ft 55 10
-6
59.6 10
-6
Typical oil content
of compressed air
mg/m
3
< 3 < 3
dram/cu.ft < 1.6 10
-6
< 1.6 10
-6
Engine oil consumption
(maximum)
g/h 155.8 155.3
oz/h 5.5 5.5
Compressed air temperature
at outlet valve
°C 110 110
°F 230 230
Noise level
Sound pressure level (LP), measured acc. to ISO 2151/
EPA under free field conditions at 7 m distance
dB(A) 72/76 72/76
- Sound power level (LW)
complies with 2000/14/EC
dB(A) 100 100
- Sound power level (LW)
complies with 84/533/EEC and 85/406/EEC limits
dB(A) 104 104
