Instruction Manual
62 2954 2510 03
4.8 Oil and oil filter change
4.8.1 Engine oil and oil filter change
See section 4.5 Preventive maintenance schedule for the compressor.
4.8.2 Topping up the compressor oil
Topping up compressor oil
(1)
(2)
1 Stop the compressor. Wait a few minutes until the pressure is released through
the automatic blow-down valve. Make sure that all pressure is released by
loosening the filler plug (1) one turn.
2 Wait 10 minutes so that the oil level is constant.
3 Remove the filler plug (1) and top up with oil until the pointer of the oil level
gauge (2) is in the upper part of the green area.
4 Reinstall and tighten the filler plug (1).
