Instruction Manual
2954 2510 03 33
3.1.3 Towbar levelling (option)
The towbar is equipped with an adjustable spring loaded levelling device.
To adjust:
1 Slide back the rubber bellows (1).
2 Turn the nut (2) clockwise to increase the spring load for lifting the towbar; turn the nut (2)
counter clockwise to decrease the spring load for lowering the towbar.
3 Slide the bellows (1) over the nut.
3.1.4 Lifting instructions
To lift the compressor, use a lift truck or crane with sufficient capacity (weight: see indication on
9Dataplate).
See to it that the compressor will be lifted vertically and remains level.
Lifting positions of unit
+
-
(2)
(1)
Lifting acceleration and retardation must be kept within safe limits (max. 2xg).
Helicopter lifting is not allowed.
Lifting is not allowed when the unit is running.
