Instruction Manual
2954 2510 03 31
3.1.1 Parking instructions
Uncouple vehicle. At compressors equipped with ABS brakes the brakes will be activated.
Apply parking brake by moving the lever (1) in the direction of the arrow.
Connect the safety chain (2) to the eyes (3) on the towbar (4). You can move the towbar (4)
upwards and secure it by connecting the chain (5) to the eye (6).
Place the compressor as level as possible; however, it can be operated temporarily in an out-of-level
position not exceeding 15°. If the compressor is parked on sloping ground, immobilize the
compressor by placing wheel chocks (available as option) in front of or behind the wheels.
Locate the rear-end of the compressor upwind, away from contaminated wind-streams and walls.
Avoid recirculation of exhaust air from the engine. This can cause overheating and engine power
decrease.
Rear-end of compressor upwind
(1)
(6)
(3)
(5)
(2)
(4)
It is not allowed to leave ABS-equipped compressors parked for a long period
with pressure engaged brakes only. Also use the parking brake.
