Instruction Manual
106 2954 2510 03
Compressor
1)
Air required for engine and compressor element cooling, for combustion and for compression.
Compressor dimensions
Designation XRHS 506 - XRHS 1100 CD6,
XRVS 476 - XRVS 1000 CD6
Capacity of compressor oil system l 75
US gal 19.8
Imp gal 16.5
cu.ft 2.6
Net capacity of air receiver l 143
US gal 37.7
Imp gal 31.5
cu.ft 5
Capacity of fuel tanks
wagon / tandem
l 796 / 538
US gal 210 / 142
Imp gal 175 / 119
cu.ft 27.8 / 19.0
Air volume at inlet grating (approx.)
1)
m
3
/s 14.6
cfm 3.0 x 10
4
Designation All Units
Length mm 5640
in 220
Width mm 2100
in 81.9
Height mm 2460
in 95.9
Weight (ready-to-operate) See indication on dataplate
