Instruction Manual
2954 2510 03 21
Warning! Part under pressure.
Do not stand on outlet valves.
Start-Stop indication of switch.
Do not run the compressor with open doors.
Lifting permitted.
Use diesel fuel only.
5.5 bar (80 psi)
Tyre pressure.
Sound power level in accordance with Directive 2000/14/EC
(expressed in dB (A)).
Fork lifting permitted.
Don’t lift here.
Read the instruction manual before lifting.
Filler cap coolant.
Read the instruction manual before topping up with coolant.
Service point.
Circuit breaker.
Do not run the compressor when the baffles are not in the right position.
ABS braking system, emergency relay valve. See section 5.5.2.
