Instruction Manual
36 2954 2510 03
Settings
Commisioning
After connecting the power all symbols in the display will blink. Now the actual time has to be set
before the heater can be operated.
Press button (1); time blinks. Set time with buttons (2) or (3).
Press button (1); time is displayed, colon blinks.
Setting the time
Press button (1) longer then 3 sec.; time blinks. Set with buttons (2) or (3). Briefly press button (1);
time is displayed, colon blinks.
Setting heating period
Press button (1) longer then 3 sec.; time blinks. Wait till the display indicates "setting heating
period"; heating symbol and time blink. Set heating period (10 to 120 min) using button (2) or (3).
Press button (1); time is displayed, colon blinks.
Setting pre-settings
By pressing button (1) once, twice or three times you will select pre-set time 1, 2 or 3.
The display shows e.g. pre-set time 1 and symbol 1. Set the pre-set period with buttons (2) or (3).
With button (4) you can activate or deactivate the pre-set period. When activated the symbol "ON"
appears and the symbol "1, 2 or 3".
Operation
Switching ON the heater
Press button (4). The heating period lasts ..minutes. The display shows: remaining heating time and
symbol 7.
Switching OFF the heater
Press button (4). The heater will run idle for about 3 minutes. The display shows: actual time.
Continuous operation
Press and hold button (3), then press button (4); now the heater will be operating till button (4)
(heater off) is pressed.
Activating/ deactivating pre-set time
Select pre-set time 1, 2 or 3 by pressing button (1).
Activate the selected time by pressing button (4).
The display shows: symbol "ON" as well as the selected pre-set time, "1, 2 or 3".
If you do not press the button within 5 seconds the mode is changed to “setting
heating period”.
