Rear view
Main components
Ref Name
AF Air filter
AO Air outlet
AS Silencer
BV By-pass valve, oil cooler
Ca1 Pre-aftercooler
Ca
Ca2
Aftercooler
Ci Intercooler
Co Oil cooler
Daa Automatic condensate outlet, aftercooler
Dai Automatic condensate outlet, intercooler
Dmo Oil drain valve, gear casing
Eh High-pressure compressor element
El Low-pressure compressor element
ER Energy recovery system
ERwi Water inlet, energy recovery system
ERwo Water outlet, energy recovery system
EWDa Electronic water drain, aftercooler
Instruction book
16
