Ref Name
EWDi Electronic water drain, intercooler
E1 Elektronikon regulator
FC Oil filler cap
FN Cooling fan
IMD/IND Integrated dryer
M1 Drive motor
M25 Fan motor
MTa Moisture trap, aftercooler
MTi Moisture trap, intercooler
OF Oil filter
S2 Emergency stop button
SG Oil level sight-glass
SVd Safety valve, dryer
SVh High-pressure safety valve
SVl Low-pressure safety valve
TV Load/no-load valve
US Silencer
WI Cooling water inlet
WO Cooling water outlet
Y1 Loading solenoid valve
1 Flange, connection to MD dryer
2 Flange, access to silica gel bags
Optional equipment
Following equipment is available as an option:
Full-Feature
The compressor is additionally provided with an IMD adsoption dryer. The dryer is integrated in the bodywork
and removes moisture from the compressed air.
Connections
This compressor can be provided on the compressed air outlet and water pipes with:
ANSI flanges
Motor temperature protection
Thermistors are embedded in the windings of the drive motor to warn the operator if the temperature becomes
too high and to shut down the compressor, thereby protecting the motor from overheating.
Instruction book
17
