Atomos Shogun Studio 2 User Manual

Connecting media
The Master Caddy Docking Station allows you to connect your media to your computer.
For information on using the Master Caddy Docking Station and the different models avail-
able, refer to "Master Caddy Docking Station" on page 21
Attaching Media to a Master Caddy Docking Station:
1. Eject the media from your SHOGUN STUDIO 2.
2. Align your AtomX SSDmini or Master Caddy II so that the SATA III connector lines up
with the SATA II connector on the Docking Station. Media can’t be inserted the wrong
way round.
3. Gently slide your media all the way into the Docking Station until it stops at the end
of the drive slot. Ensure that the media is properly attached.
Never force the media into the docking station, just in case something
isn’t set up or aligned properly
The SHOGUN STUDIO 2 disk slot does NOT have a release latch for media.
It is a friction-fit system. To remove simply pull the media out using the top
and bottom tabs on the media itself.
