Atomos Shogun Studio 2 User Manual

Battery Menu
Power Down
On the left of the screen is a power icon. Tap and hold this button for 4 seconds to shut
down the unit.
Tap to Lock/Unlock
This image provides information on how to lock and unlock the display of your SHOGUN
STUDIO 2.
Battery
When a battery is attached to your SHOGUN STUDIO 2, the Battery icon on the Power
menu screen indicates the remaining power in the attached battery. The numerical figure
above the battery icon will indicate the remaining power in volts whilst the shading inside
the battery icon provides a visual indication of the current power level.
SHOGUN STUDIO 2 2 uses standard NP-F/L-Series compatible batteries.
DC Power
The power plug icon represents DC power.
