Technical Specifications
Physical Specifications
Without batteries &
media
5.0kg / 11lb
Dimensions (W x H x
D mm)
447 x 152 x 280mm, 17.6 x 6.0 x 11.0”(without
rack ears), 490 x 152 x 280mm, 19.3 x 6.0 x
11.0” (with rack ears)
Mounting points Removable rack ears and desktop feet
Dual Screen Dual Screen, Recorder and switcher
Environmental
Ambient operating
temperature
Up to 40 Degrees Celsius
Construction and Control
Body Aluminium alloy chassis
Cooling Actively controlled fans and heat sink
Tally light
Rear and front (Red border on the display indic-
ates record)
Multi-function button Trigger dual record
Power
Continuous power Dual PSU
DC in connector Dual IEC C14
Display
Touchscreen SuperAtom IPS panel (capacitive touch)
Size Dual 7.2"
Resolution Dual 1920 x 1200 px
PPI 327 per screen
Bit Depth 10-bit (8+2 FRC)
Backlight Type
Dynamic zoned back light 3", Dynamic Full Array
