Audio Embed
Allows you to embed the analog audio channels into the digital signal, so that when you
output the video signal over HDMI/SDI this audio is also output as part of the digital sig-
nal. The available options will depend on how many channels of audio are coming in. Tap
to cycle through the options.
With SDI inputs, your SHOGUN STUDIO 2 can record 12 embedded audio
channels, instead of the usual 8 channels of audio when using HDMI.
If analog audio is recorded it will be placed as track 1-2 with embedded
audio moving to 3-4. Note if analog channels are turned on but no audio is
present, in many video players you will not hear silence as they often just
play the first stereo pair. In an NLE you can easily access all the recorded
tracks.
Audio Out
Allows you to set the level to be sent over XLR cables connected to the 2x XLR outputs.
Tap to cycle through the options. The XLR outputs are for monitoring and the audio chan-
nel routed to them can be selected via the headphones selection.
