Atomos Shogun Studio 2 User Manual

Inserting the Master Caddy III into the media slot
When inserting the Master Caddy III into the media slot on your SHOGUN STUDIO 2,
ensure that the SATA connectors on the disk line up with the SATA connectors on your
device. Gently push the Master Caddy III into place, but never force the disk just in case
something isn’t set up or aligned properly.
If you experience difficulty when inserting the Master Caddy III to your device, the drive
may not be sitting correctly in the Master Caddy or the screw heads may not be flush with
the casing of the caddy. A quick visual check will confirm this. Remove the drive and re-
inserting it in the Master Caddy III. For information on attaching media to a Master Caddy
Docking Station see "Connecting media" on page 163.
Master Caddy II drives are compatible with SHOGUN STUDIO 2.
