Use these icons to adjust the audio delay by whole frames. This option allows you to delay
the analog audio with respect to the digital audio so that it is in sync with your video
source.
Audio In
Tap on Audio In to select the input level that matches your input type.
Options available are:
l
Mic Level (-40 dBu):Sets the analogue input channel to Mic Level via the XLR to
XLR connector. With Mic Level selected you also have the option to provide 48V
phantom power should your microphone require it. Please only use this when your
microphone supports it and if unsure please consult the manual for the mic you are
using.
l
Line Level (-10 dBu): Sets the analogue input channel to Line Level via the XLR
breakout cable.
l
Pro Level (+24 dBu) Sets the analogue input channel to Pro Level Audio to via the
XLR breakout cable. Analogue gain can then be tuned by incremental increase or
decrease of up to +/- 20dB individually for both left and right channels.
It is not possible to vary the gain if the signal input is from the HDMI con-
nection because this is digital and is embedded in the signal. You can usu-
ally adjust this from the camera, please see your camera manual for
operational details.
SHOGUN STUDIO 2 Mic input supports dynamic and powered microphones
only. When using these, audio must be set as Mic Level
Audio during Playback Mode
When you enter into Playback mode on the your device, it will only output channels 1/2
on the headphones, please bear this in mind when you select the audio channels for
recording.
