SC1000 Fiber Laser Cutting CNC System User’s Manual Version： V1.00
2017 年 3 月 27 日
relocate the breakpoint first then you can continue your cutting process. If user choose “Stop”
manually during cutting process, the current cutting process information will be delate and user
must relocate the breakpoint first in order to find the last cutting location before continuingly cutting.
2) “Dry Cut”: Cut without laser.
3) “Frame”: SC1000 will do the cutting process without laser and Z axis will not follow (default). If user
wants Z axis to follow, please select “Enable follow when dry cut”.
4) “Sim”: SC1000 can simulate laser’s real running path.
5) “Loop”: User can use it to cut one graphic repeatedly.
3.4.2 Running parameters
User can set up running parameters through this part. The descriptions of each parameters show as
below:
Name of running parameters
Descriptions
Default value
Run control
Go Frame Speed (mm/s)
Move speed when go frame.
10.00
Move Speed (mm/s)
Move speed without laser.
10.00
Move Acc (mm/s2)
Move accelerated speed without laser.
200.00
Empty Move Acc Time
(ms)
Accelerated time when empty move.
125.00
Cut Acc (mm/s2)
Accelerated speed when cutting.
200.00
Process Acc Time (ms)
Accelerated time when cutting.
125.00
Circle Precision (mm)
0.01
Corner Precision (mm)
0.10
Laser
Control
Laser Freq (Hz)
Laser frequency.
5000
Peak Current (%)
Peak current in proportion.
100
Auto Control Shutter When
Process
Check
Check
Gas Control
Default Pressure (Bar)
4.00
Gas On Delay (ms)
Gas on delay when cutting
0
First Gas On Delay (ms)
First gas on delay when cutting
0
Gas Change Delay (ms)
0
Follow
Control
Short Move Unlift Length
(mm)
10
Enable Frog Style Up
Enable frog style up when move from one
cutting point to another after check.
