Descriptions
System alarm has two different alarms, one is a little bit harmful, such as “follow error alarm of
cutting head”, once the warning condition has been cleared, SC10000 will auto clear the alarm. The
other one is more harmful, such as “servo input alarm”, once the warning condition has been
cleared, user must clear the warning manually to make sure the safety of equipment and user.
4.2 Normal exceptions and handling
When some normal exceptions occurred, user can do trouble-shooting by SC1000’s diagnose,
which can save user’s time and improve the efficiency.
Graphic 4-1 Normal exceptions troubleshooting flow:
4.2.1 System communication exceptions
SC1000 was designed based on Ethernet, all the equipment are connected through Ethernet.
When SC1000 can’t connect with motion control card or FTC, user can check it out step by step as
below:
1) Please check whether if the IP has been set.(IP of motion control card/FTC has already been set
before exporting the factory)
